Feature:
1.The energy density is high, the heat input is low, the amount of thermal deformation is small, and the melting zone and the heat-affected zone are narrow and deep.
2.High cooling rate, which can weld fine weld structure and good joint performance.
3.Compared with contact welding, laser welding eliminates the need for electrodes, reducing daily maintenance costs and greatly increasing work efficiency.
4.The weld seam is thin, the penetration depth is large, the taper is small, the precision is high, the appearance is smooth, flat and beautiful.
5.No consumables, small size, flexible processing, low operating and maintenance costs.
6.The laser is transmitted through fiber optics and can be used in conjunction with a pipeline or robot.
Application:
Mainly aquatic stainless steel, carbon steel, aluminum alloy carbon steel, stainless steel, aluminum alloy, galvanized plate and other massive shell cabinets, hardware furniture lighting, guardrail doors and windows, new energy, mechanical and electrical products, mechanical and electrical products, etc.
1.Save manual: L -shaped left welding left and right welding, the machine does not interrupt the operation
2.Replacement of traditional welding: Reduce polishing, speed is 2-5 times faster
3.Six -axis welding is more flexible: welding can be welded at different angles, such as tube electric vehicles, furniture, etc.
4.Higher cooperative operation: two robots in large products can coordinate welded at the same time
5.Precision products are more cost -effective: seamless or small sheet metal welding. No need to send wire, save welding wire costs
Specification:
|
Power |
1500W, 2000W,3000W |
|
Laser wavelength |
1070nm |
|
Output power stability |
＜3% |
|
Frequency |
0.5Hz-100KHz |
|
Adjustable power range |
10-100% |
|
Beam quality |
1.1 |
|
Output fiber length |
10m |
|
Cooling method |
Chiller |
|
Laser source |
Raycus |
|
Welding head |
DP customized welding head |
|
Positioning precision of space |
0.05mm |
|
Robot Max. Moving radius |
1550mm |
|
Max. payload |
12kg |
